The Carne complex at Luxor in upper Egypt is the largest temple ever built. Sprawling over more than 1 and a half square miles. The central temple of Ammoon alone extends over 62 acres. St. Peter's Basilica by way of comparison covers about 5 and a half. Today we'll explore how this iconic Egyptian temple was constructed. We'll begin with the colossal first pylon of the temple of Amoon. At 370 ft long and more than 142 ft tall, this monumental gateway is the largest of its kind. It dates to the reign of Nectonbo I founder of Egypt's last native dynasty
who reigned in the mid 4th century BC. The pylon is made of sandstone from Jebel Elsula about 100 m south of thieves. Strong enough to bridge gaps of 30 ft or more without cracking. This stone was cut from Nileside cliffs. By the time the first pylon was built, iron picks and chisels had replaced the bronze tools used during the New Kingdom. The methods of quarrying, however, had changed little since the age of the pyramids. Teams of men paid in bread and vegetables cut narrow trenches around three sides of a block, which was then undermined to free it. After being roughly dressed to the desired shape, blocks were hauled to the Nile on wooden sledges. barges carried them upstream to Carac.
Despite the great size of the planned pylon, the foundation consisted only of a shallow trench filled with layers of sand and gravel. The superructure was faced with huge sandstone blocks laid, as usual in Egypt, with virtually no mortar. The little mortar that was used was a simple compound of gypsum and sand meant to even the courses, not bond the stones. As the pylon rose, construction ramps encircled it. Part of one still stands beside the south tower. Like most ramps, it was supported by mudbrick walls built at right angles to the pylon. The spaces between were packed with mud and sometimes reinforced with timbers.
A wall painting in the tomb of Rekier across the Nile from Carnack illustrates the construction of a similar structure. Workmen fill jars of water to blend with earth and chaff. The mud is then carried in baskets to the masons who pack it into molds for drying. Finally, the finished bricks are piled into a ramp. The first pylon was never completed, which is why its surface is so rough. If construction had continued, men with chisels and stone pounders would have worked from the top down, smoothening the facades. The pylon of the temple of Horus at Edfu, built about a century and a half later, illustrates what the structure would have looked like had it been finished.
Perhaps the most remarkable monument inside the temple of a moon at Carac is the obelisk of Hepsuit. Originally, it was one of a pair set up in what is now the courtyard between the fourth and fifth pylons. At 97 ft and 323 tons, it's the second largest extent obelisk eclipsed only by the Lateran obelisk in Rome. According to an inscription on its base, it and its twin were completed in only 7 months. Obelisks were cried at Aswan, Egypt's premier source of granite. Too hard to work with copper or bronze chisels, granite was sometimes heated by fire and then cracked with poured water.
The work of shaping an obelisk, however, had to be done with pounders, 10 or 12lb balls of doerite, an extremely hard stone from the eastern desert. Workmen crouched about an arm's length from one another, methodically striking the granite. To judge from modern attempts, it would have taken an entire working day to remove an inch of stone. A gigantic unfinished obelisk, which would have weighed nearly 12,200 tons, is still half embedded in the quarry at Aswan. An estimated 130 workmen labored for a year to excavate the narrow trenches on either side. They had already begun to undercut the monolith when deep cracks were discovered in the stone, causing the project to be abandoned.
At Shepsuit's obelisk, by contrast, was successfully removed, the workmen grinding away with their pounders until only a narrow ledge of stone remained beneath the shaft, and the monument could be broken free with levers. The Egyptians used wooden sledges to move heavy loads. A relief from the tomb of a nomark named Judah Hoteep, for example, shows 172 men pulling a 60-tonon statue poised on a massive sledge. To judge from the reliefs at Daryl Bahari, similar sledges were used to transport Hepsuit's obelisks. After an obelisk was maneuvered onto its sledge, palm fiber ropes were fastened to it, especially if the track was moistened to reduce friction. Only about 600 workmen, one man per half ton, would
have been needed to haul the monolith to the river. The 1,000 ton colossus in the mortuary temple of Ramsy's II, three times the weight of Hepsuit's obelisks, was moved by the same method. If the Daryl Bakari reliefs are accurate, Hepsuit's two obelisks were transported up the Nile on a single colossal barge towed by many smaller ships. To cope with the vast weight of the obelisks, the barge was probably a solid raft made of tree trunks. At Carnac, the obelisk may have been hauled up an enormous sand ramp and then eased down to its pedestal from the crest. The fact that two obelisks were being erected at the same time would have facilitated the process since workmen could have stood on one obelisk's ramp
as they raised the other into position. Alternatively, a lower ramp may have been built and one edge of the shaft slotted into a groove on the pedestal. The obelisk could then have been gradually elevated with levers, braced with mudbrick and wood until it was vertical enough to be hauled upright with ropes. Impressive though the obelisk of Hepsuit is the most iconic part of the Carneak Temple complex is the hypoyle hall covering 58,000 square ft well over an acre. The hall is famous for its 134 sandstone columns. The largest are 75 ft tall and 32 ft in circumference. The columns of the Pantheon are 39 ft tall. Despite its scale, the hypo style hall was built
relatively quickly. Most of the structure dates to the reign of Sedi the first. The decoration was completed by his son Ramsy's II. The foundations of the columns consisted of a thin layer of sand topped by a few courses of small rectangular blocks. These rudimentary underpinnings were adequate in antiquity. But in the late 19th century, when the alovium beneath them came to be saturated by the rising level of the Nile, 11 columns collapsed. Mud brick ramps wrapped around the columns as they rose, eventually filling the entire hall with packed mud and rubble. Once the massive earth reached the level of the capitals, the huge sandstone roof blocks were simply laid
on top. As the ramps were gradually removed, sculptures used them as scaffolds, smoothening and decorating the columns from the top down. The Carne Temple Complex was a work of millennia. The methods used to build its kiosks and chapels and halls, however, changed little from beginning to end. The same mudbrick ramps, the same ruddy sandstone, the same cloudless desert sky. For a closer look at the temple, check out my video on scenic roots to the past linked on screen and in the description.
